Free from hand-washing work. Working efficiency may be elevated.
Patent pending |
|
By depressing only one push-button switch, the AUTO washing may start.
As a result, embarrassed hand-washing work. will be eliminated. |
|
|
 |
|
 |
Befor |
|
After |
|
|
| |
Features |
|
| |
- By depressing only one push-button, AUTO washing can be carried out.
- Washing completes within approx. 5 minutes per one unit.
- Inner parts of bottles can be washed easily simultaneously together with the outside washing.
- Because splash of water is less, indoor washing work is possible in the cold winter season.
- Compact designing may save installation spaces.
- Simple constructions may afford easy maintenance.
- Rust preventive all stainless steel specifications are designed.
|
 |
| |
|
| |
Specifications |
|
| |
Type |
HK-300 |
Diameter of applicable hose |
Diameter = 30 cm or 35 cm |
Type of prime mover |
3-phase200V 0.5kW |
Outline dimensions |
H2000×W1200×D900 |
Body materials |
SUS |
Mass weight |
300kg |
|
|
| |
The Customer is requested to connect the Customer procured items with this machine.
- Air compressor (0.4〜0.6MPa/1.0 m3)
|
|
| |
Major uses |
|
| |
Washing of Flexible duct hose (Air duct) after recycling. |
|
|
